Product attributes
Brand：EVERTOP
Models： DCGF18-18-6
Certificate： CE
Country of origin： CHINA
Trading information
Minimum minimum order size ：1 Set
Price：USD 15,000 – 150,000 per Set
Payment method：30% by T/T in advance as deposit, balance 70% by T/T or irrevocable L/C at sight before shipment
Supply capacity ：20 sets per month
Delivery date ：15-30 days
Conventional packaging：Wooden case
Product description
1. The carbonated soda water filling machine suspending bottle-necks cramping design makes the whole production line more stable during the working process and it also avoids malfunctions caused by the different of thickness and height of the bottle.
This design also dramatically reduces the required number of changeable parts, makes it more convenient to change the different size bottles.
2. The advanced technology isobaric filling technology is used in this machine. Filling quickly and the amount of the liquid can be controlled accurately. Also the beverage-holding tank is fully closed and the CIP interface is installed.
3. Magnetic torque is used for screw capping, and the force of screw capping can be adjusted freely. It can use constant force screw the plastic caps and will not damage the caps.
4. Horizontal swirl wind-power cap-managing device is used to avoid damaging the surface of cap. And when there is shortage of caps in the cap storage tank, caps will be fed automatically.
5. Human-machine interface touch-screen is adopted in this machine. The liquid level in the tank can be controlled automatically. The filling and capping will stop automatically when there is no bottle.
6. All parts that have direct contact with the beverages are made of high-quality stainless steel. And the main electrical components are from famous international companies.
7. The filling machines we offer are listed below some information that will help you understand how to select the type and capacity filler you need for your operations.
| Model: | DCGF12-12-5 | DCGF16-12-6 | DCGF18-18-6 | DCGF24-24-8 |
| Capacity:500ml | 2000-3000bph | 3000-4000bph | 4000-5000bph | 5000-8000bph |
| Bottle shape: | round or square | |||
| PET bottle: (mm) | (Bottle Diameter): φ50-φ110mm, (Height): 150-310mm (Volume: 250ml -2000ml) | |||
| Cap: | Plastic screw cap | |||
| Filling precision: | ≤±5mm | |||
| Power (KW) | 3.0 | 4.0 | 4.2 | 5.2 |
| Filling pressure: (MPa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 |
| Rinsing pressure: (MPa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 |
| Overall size:(mm) | 1900*1500*2350 | 2250*1650*2350 | 2600*1965*2350 | 2980*2200*2250 |
| Weight: (KG) | 3000 | 3500 | 4000 | 4500 |
| Model: | DCGF32-32-10 | DCGF40-40-12 | DCGF50-50-15 | DCGF60-60-15 |
| Capacity:500ml | 8000-10000bph | 10000-15000bph | 16000-20000bph | 20000-24000bph |
| Bottle shape: | round or square | |||
| PET bottle: (mm) | (Bottle Diameter): φ50-φ110mm, (Height): 150-310mm (Volume: 250ml -2000ml) | |||
| Cap: | Plastic screw cap | |||
| Filling precision: | ≤±5mm | |||
| Power (KW) | 6.2 | 7.5 | 8.5 | 9.8 |
| Filling pressure: (MPa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 |
| Rinsing pressure: (MPa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 |
| Overall size:(mm) | 3880*2200*2250 | 4000*2250*2250 | 5500*3500*2250 | 6500*5500*2250 |
| Weight: (KG) | 6000 | 7000 | 8200 | 9500 |
